Leukemias are considered as the most common form of malignant disorders in children. Acute lymphoblastic leukemia is responsible for approximately 70 % of the cases of leukemia in children while acute myeloid leukemia account for 30 % of the cases. Patients with leukemia can present with symptoms related to loss of normal functioning cells such as anemia, bleeding disorders, and infections, or symptoms related to the expansion of the leukemic cells and metastasis. Cytogenetic and molecular testing is essential as it can have an impact on the treatment and prognosis of the patient. Intensive combination chemotherapy is usually needed for the induction therapy, followed by consolidation therapy with or without stem cell transplantation. Patients with Philadelphia chromosome should be administered a tyrosine kinase inhibitor and the option for stem cell transplantation.
Are you more of a visual learner? Check out our online video lectures and start your pediatric oncology course now for free!

ALL Peripheral Blood

Image: “Acute lymphoblastic leukemia (ALL), peripheral blood of a child, Pappenheim stain, magnification x100.” by Christaras A. License: CC BY 2.5


Leukemias are defined as a group of different malignant disorders that involve the white blood cells. Acute lymphoblastic leukemia (ALL) is ranked as the most common malignant disease in children. Another common type of pediatrics leukemias is known as acute myeloid leukemia. Acute myeloid leukemia is characterized by the replacement of the normal bone marrow cells with dysplastic hematopoietic cells.

Epidemiology of Pediatric Leukemias

Acute lymphoblastic leukemia is currently believed to be the most common form of cancer in children with an annual incidence of 4.9 cases per 100,000 children aged between 0 and 14 years.

For obscure reasons, Caucasian children seem to be at slightly higher risk of developing acute lymphoblastic leukemia compared to children of other ethnicities. Boys aged between 2 and 5 years have the highest risk of developing acute lymphoblastic leukemia.

The majority of the cases of ALL have no predisposing risk factors. On the other hand, certain specific pediatrics populations such as children with Down syndrome or Wiskott-Aldrich syndrome seem to have a higher risk of acquiring ALL compared to the general population.

Acute myeloid leukemia is more common in adolescents but still can be diagnosed in young children. Approximately, one third of new cases of pediatrics’ leukemias is attributed to acute myeloid leukemia. Ethnic differences in the incidence of acute myeloid leukemia in the pediatrics’ population are not observed as opposed to ALL.

Etiology of Pediatric Leukemias

The exact cause of ALL is unknown. In most cases, however, certain risk factors have been previously shown to increase the incidence of ALL. The most common genetic disorder to be clearly associated with an increased risk of ALL is Down syndrome. Other possible risk factors include Wiskott-Aldrich syndrome and ataxia-telangiectasia.

Myeloblast with Auer rod smear

Image: “Myeloblasts with Auer rods seen in Acute Myeloid Leukemia (AML).” by Paulo Henrique Orlandi Mourao. License: CC BY-SA 3.0

The possible causative role of radiation exposure in ALL has been extensively studied and debated over the last few decades. The current consensus is that radiation exposure is unlikely to increase the risk of ALL but may be a significant risk factor for acute myeloid leukemia.

Acute myeloid leukemia on the other hand has been linked to many risk factors. Most of the risk factors that have been shown to be associated with acute myeloid leukemia are known to be associated with defects in deoxyribonucleic acid (DNA) repair mechanisms.

Acute myeloid leukemia is more likely to be associated with fusion genes which occur as a consequence to chromosome translocations. The products of these fusion genes are believed to be responsible for the loss of the normal property of apoptosis in the leukemic cells which allow them to expand.

Radiation exposure might have a significant role in developing acute myeloid leukemia in children but more research is still needed. For instance, while the risk of acute myeloid leukemia seems to be higher in Japan after the atomic explosions at Hiroshima and Nagasaki among children, the effects on incidence are seldom noticed in adults. Additionally, the risk of acute myeloid leukemia in children who live near nuclear plants was debated to be higher but definite proof from adequate research is still lacking to support this claim.

Several genetic disorders have been shown to be associated with an increased risk of acute myeloid leukemia which include Down syndrome, Diamond-Blackfan anemia, Fanconi anemia, and Bloom syndrome. Dyskeratosis congenita has been associated with a relative risk of developing acute myeloid leukemia that is 200 higher than the normal population. All of these syndromes share the same common pathologic mechanisms of impaired DNA repair.

Pathophysiology of Pediatric Leukemias

Acute lymphoblastic leukemia is characterized by the dysregulated proliferation and mono-clonal expansion of a lymphoid progenitor cell that is genetically abnormal. The resulting lymphoid cells show expression of normal B and T cell genes and carry some of the surface antigens expressed by these lymphocytes.

Another important pathologic step in acute lymphoblastic leukemia is the presence of leukemic stem cells which lose the ability to go into apoptosis.

In acute myeloid leukemia, the normal bone marrow is replaced by abnormal leukemic cells that are the product of fusion genes resulting from chromosome translocations. The different risk factors associated with acute myeloid leukemia are known to be associated with impaired DNA repair mechanisms.

In addition to impaired DNA repair mechanisms, the cells also need to express certain genes that would render them immortal, i.e. no longer undergoes programmed cell death despite having abnormal genetic makeup.

Because the bone marrow in acute myeloid leukemia is replaced by abnormal leukemic cells, normal functioning cells are no longer produced. Therefore, thrombocytopenia, anemia and neutropenia are usually evident in the late stages of the disease. The patients’ symptoms and morbidity are usually related to the loss of the normal functioning cells rather than the production of abnormal leukemic cells.

An interesting scenario that has been associated with acute myeloid leukemia is the development of the disorder as a complication to antineoplastic cytotoxic drugs. Patients undergoing treatment for Hodgkin lymphoma who are administered an alkylating agent especially if combined with radiation therapy are at risk of developing overt acute myeloid leukemia.

Prognosis of Pediatric Leukemias

Long-term cure in acute lymphoblastic leukemia is possible but is usually dependent on the child’s age and white blood cell count at diagnosis. Other possible prognostic factors in acute lymphoblastic leukemia include the number of leukemic blasts at 8 days and 29 days post chemotherapy and the biologic characteristics of the leukemic blasts.

Children who are aged between 1 and 9.9 years, have a white blood cell count < 50,000 at time of diagnosis, do not have any poor prognostic cytogenetic features and show good response to initial chemotherapy are considered as standard-risk patients. Favorable cytogenetics include trisomy 4 and 10.


Image: “Immature large blast cells in Acute Lymphoblastic Leukemia.” by VashiDonsk. License: CC BY-SA 3.0

Low risk patients are defined as patients who have less than 0.01 % blasts at 8 days and 29 days post-chemotherapy initiation. This group of ALL patients have a 5-year survival of approximately 95 %.

On the other hand, patients who are younger than 1 year, or who have poor-prognostic cytogenetics such as Philadelphia chromosome are considered as very-high-risk.

Unfortunately, 5-year survival in very-high-risk ALL can range between 30 to 80 % and is difficult to predict. Perhaps initial response to chemotherapy and minimal residual disease are key in the prediction of prognosis in this group of ALL patients.

Acute complications of ALL are common and include tumor lysis syndrome, renal failure, sepsis, thrombosis, and central nervous system involvement. Long-term complications are also identified in survivors and might include secondary malignant disease or cognitive defects.

The survival rate of acute myeloid leukemia is usually dependent on the etiology and the child’s age at time of presentation. For instance, children who are younger than two years of age and have Down syndrome usually have a favorable outcome if they develop acute myeloid leukemia. The overall survival rate in this group of patients can be as high as 86 %.

Cytogenetic abnormalities in acute myeloid leukemia have an impact on the risk of recurrent disease. For instance, translocation (8;21) which is most commonly found in children with myeloblastic leukemia has a low risk of recurrent disease, whereas monosomy 7 and monosomy 5 carry a high risk of recurrence.

Certain mutations that are commonly identified in children with acute myeloid leukemia might also have an effect on overall survival. For example, nucleophosmin (NPM1) mutation can be associated with a favorable outcome, whereas mixed-lineage leukemia (MLL) mutations can be associated with a poor prognosis.

Clinical Presentation of Pediatric Leukemias

The most common presentation of ALL is that of bone marrow failure. Children present with anemia, thrombocytopenia and neutropenia. Bone pain and arthritis are very common in children with B-cell ALL. In contrast to acute myeloid leukemia, fever which is also common in ALL is rarely due to sepsis.

Patients with ALL can also complain of fatigue, bleeding complications and petechiae. Lymphadenopathy and hepatosplenomegaly are common in ALL and acute myeloid leukemia. Patients with B-cell ALL are more likely to have abdominal, head, neck and central nervous system masses. On the other hand, patients with mainly T-cell lineage ALL usually have mediastinal disease that can present with respiratory distress and stridor.

Patients with acute myeloid leukemia usually have a similar presentation to ALL but bleeding complications are slightly more common. Easy bruising, epistaxis, gingival bleeding and intracerebral hemorrhage are possible bleeding complications known to be associated with acute myeloid leukemia.

Fever is also common in acute myeloid leukemia and is usually a consequence to an infectious disease. Therefore, patients might present with cough, shortness of breath and chest pain which are signs of pulmonary infection. Meningitis can also happen in patients with acute myeloid leukemia.

Patients with acute myeloid leukemia can present with lymphadenopathy, and hepatosplenomegaly, similar to ALL. Mediastinal masses are usually rare in acute myeloid leukemia compared to ALL.

Another important distinctive feature of acute myeloid leukemia from ALL is bone pain and arthritis. While ALL patients commonly complain of arthritis, especially those with B-cell ALL, patients with acute myeloid leukemia rarely develop bone pain or arthritis.

Diagnostic Workup for Pediatric Leukemias

Patients with suspected ALL should undergo a systematic approach to reach a diagnosis. The first step is to perform a complete blood count which should be interpreted by an experienced hematologist. The presence of blasts is very characteristic of ALL. The next step once the presence of blasts is confirmed is to perform a flow cytometry study which can differentiate between T-cell and B-cell lineage ALL.

Patients with ALL are at risk of developing tumor lysis syndrome. Serum levels of uric acid, lactate dehydrogenase, potassium, phosphorus and calcium correlate with the risk of tumor lysis.

The subsequent step in the evaluation of ALL is to perform a bone marrow aspiration for immunophenotyping. Certain B-cell markers such as CD10 have both a diagnostic and prognostic role and their presence should be determined. Patients with B-cell ALL should be differentiated into mature or non-mature B-cell ALL as this can have an impact on the treatment and prognosis of the patient.

The most specific T-cell marker in ALL is CD3. T-cell ALL should be also classified into early, mid or late thymocytes depending on maturity.

Karyotype analysis and molecular techniques are useful in the identification of certain genetic alterations in leukemic blasts in ALL which might have an effect on the prognosis and response to treatment. Common favorable cytogenetic abnormalities in ALL include translocation (12;21), and hyperdiploidy (> 50 chromosomes/cell).

Patients that have blasts that have less than 44 chromosomes per cell, that express the MLL gene or have the Philadelphia chromosome are usually poor responders to chemotherapy and have a worse prognosis.

microscopic image of Auer rods

Image: “Bone marrow aspirate showing acute myeloid leukemia. Several blasts have Auer rods.” by VashiDonsk. License: CC BY-SA 3.0

Expression of certain genes such as NOTCH1 in T-cell ALL might be associated with a favorable outcome while mutations in the homeobox genes are usually associated with worse prognosis.

The approach to acute myeloid leukemia is similar to ALL but with certain differences that should be noted. The probability of finding a white-blood-cell count above 100,000 per micro-liter is much higher in acute myeloid leukemia. Blood smears can reveal thin eosinophilic cytoplasmic inclusions that are known as Auer rods.

Another important specific point to the workup of acute myeloid leukemia is the possibility of finding the 9;22 translocation which indicates the presence of chronic myelogenous leukemia. This cytogenetic abnormality can affect the treatment plan because patients with this chromosomal abnormality should receive tyrosine kinase inhibitors and might eventually need stem cell transplantation.

Advanced imaging techniques such as computed tomography scans and magnetic resonance imaging are indicated to evaluate the leukemic cells infiltration of the different organs in both conditions. The decision to order a certain imaging study should be based on the history, physical examination, laboratory and cytogenetic abnormalities identified. For example, ALL patients with T-cell lineage ALL might benefit from a high-resolution mediastinal computed tomography scan to assess the level of mediastinal disease involvement.

Treatment of Pediatric Leukemia

Treatment of ALL includes induction, consolidation and maintenance therapy along with central nervous system prophylaxis.

  • Induction therapy of ALL includes a combination of vincristine, prednisone, cyclophosphamide, doxorubicin and L-asparaginase for 4 to 6 weeks.
  • Consolidation therapy of ALL is usually based on multiagent chemotherapy with cytarabine and methotrexate.
  • Maintenance therapy includes methotrexate, prednisone and vincristine. Patients with ALL who have the Philadelphia chromosome should also receive a tyrosine kinase inhibitor and should be evaluated for allogeneic stem cell transplantation.

Children with confirmed mature B-cell ALL usually have a worse prognosis compared to other B-cell ALL. Such patients are more likely to have CD20 positive blasts and are more likely to develop tumor lysis syndrome. It is currently recommended to add rituximab and aggressive intrathecal methotrexate to the traditional chemotherapy regimens in this group of children.

Patients with acute myeloid leukemia should also undergo induction and consolidation therapy. Induction therapy for acute myeloid leukemia includes cytarabine combined with either anthracycline or anthracenedione.

Consolidation therapy for acute myeloid leukemia is highly dependent on the identified cytogenetic abnormalities and molecular mutations. Patients with favorable cytogenetics should receive high dose cytarabine as consolidation therapy with or without autologous stem cell transplantation.

Patients who have poor-prognostic cytogenetics should be offered allogeneic stem cell transplantation or the chance to be enrolled in an ongoing clinical trial with new chemotherapeutics because the prognosis is very poor. If both options are not available in a high risk patient, then high dose cytarabine should be used as consolidation therapy.

Patients with leukemias usually undergo intensive chemotherapy and can undergo long periods of time with pancytopenia. Therefore, transfusion support is usually indicated and the transfusion of platelets, and red blood cells is common.

Radiation therapy might be needed especially in children who will undergo bone marrow transplantation. Radiation therapy is also needed in patients with large blast masses which are common in acute myeloid leukemia. Patients with central nervous system involvement with ALL or acute myeloid leukemia can also benefit from radiation therapy.

Patients with ALL or acute myeloid leukemia are at risk of developing infections due to their neutropenia. Therefore, early recognition of a new-onset fever and adequate administration of antibiotics are essential.

Finally, it is worth to mention that most patients with ALL and acute myeloid leukemia do not need any specific surgical intervention. The most likely scenario where a patient might need a surgical intervention is related to the development of an infectious complication such as an abscess.
