As mammary carcinoma is the most frequent malignant disease in women, early detection is important. There are numerous diagnostic tools available, the mammogram being the gold standard. The next step would be developing a treatment plan that is individualized for the patient and the type of carcinoma. The following article will teach you to accurately diagnose mammary carcinoma and to initiate the appropriate therapy.
Are you more of a visual learner? Check out our online video lectures and start your course “Reproductive System Disease” now for free!

doctor palpates woman for nodes

You may read everything concerning causes, risk factors, symptoms and special types of mammary carcinoma in the following article: Breast Cancer (Mammary Carcinoma) — Causes, Classification and Symptoms

Diagnosis of Mammary Carcinoma

Patient history and clinical examinations in cases of mammary carcinoma

It is important to ask the patient targeted questions regarding the aforementioned symptoms, as well as individual risk factors.  This is followed by an examination with the patient’s upper body unclothed and her arms down, as well as with her arms raised up whereby close attention should also be paid to the aforementioned symptoms (changes in the size of the breast, differences between both sides, skin retraction, etc.).

Palpation should be done after the end of menstruation while the patient is sitting up and lying down. Hereby, the breast is divided into four quadrants and is palpated against the thorax wall, checking for nipple discharge when lightly pressing on the mammary gland. Furthermore, it is important to palpate the supraclavicular and axillary lymph nodes.

In cases where skin retraction is visible, it is important to find out if it increases when the arms are elevated. Another diagnostic tool to be used is the Jackson test, during which the skin is compressed over the palpable densification. If the skin retraction increases, the test is positive.

For the early detection of breast cancer, women over the age of 30 should be offered annual clinical exams.

Patients should be encouraged to regularly perform breast self-exams and palpation, as not all carcinoma may be detected via mammography. The majority of carcinoma (> 70%) are detected by the women themselves, which is why breast self-exam is an important method of early detection. Self-exam alone, however, may not reduce the mortality rate.

Self exam Palpate nodes

Image: “Self-Exam” by Stevenfruitsmaak. License: public domain

Diagnostic tools for mammary carcinoma



Image: “Mammogram” by Bruce Blaus. License: CC BY 3.0

Mammography is the gold standard of the instrument-based examination of the breast for the early detection of mammary carcinoma. It is being done every two years as part of a screening program for women between the ages of 50 and 70 or annually if women have a family risk factor (starting at age 30).

A mammography should also be done from the age of 35 in cases where irregularities were found during the clinical examinations, whereas women under the age of 35 should have a sonography.

In order to obtain conclusive images and to keep the radiation dose as low as possible, it is necessary to compress the breast between object table and the Plexiglas compression plate, which may be painful.

Mammography is a specific type of low-dose x-ray imaging in which radiopaque structures such as carcinoma, calcifications or fibroadenomas create shadows but appear light on the scan, whereas fatty tissue appears dark.

Normal (left) versus cancerous (right) mammography image

Image: “Normal (left) versus cancerous (right) mammography image.” License: public domain

While benign tumors mostly appear homogenous, smoothly outlined and dense, the following criteria are signs of malignant findings:

  • Asymmetric focal findings with unsharp delineation
  • Inhomogeneous band- and mesh-like shadows
  • Star-shaped thickening with spicules
  • Polymorphic clustered microcalcifications (pointing toward DCIS!)
  • Surrounding tissue: retraction phenomenon
  • Outlined thickening/retraction (skin, mammillary gland)
Typical mammogram in MLO view from clinical dataset

Image: “Typical mammogram in MLO view from clinical dataset. In the ROI demonstrated, there are micro-calcifications in the upper quadrant of the left breast.” by Openi. License: CC BY 2.0

Note: Polymorphic, clustered microcalcifications are suspicious and are to 80 or 90% a sign of in situ or early-stage carcinoma, respectively!  Mammography has a sensitivity of between 85 to 90%, depending on the tissue density: The fattier the tissue, the better the sensitivity. The specificity, however, is very limited.


Mammography findings are classified according to BI-RADS (Breast Imaging-Reporting and Data System):

BI-RADS Diagnosis/Findings Procedure Risk of carcinoma
0 Imaging has not been concluded Further clarification is necessary
1 Unremarkable findings Normal care 0%
2 Benign findings Normal care 0%
3 Unclear, probably benign findings Requiring follow-up (after six months) < 2%
4 Suspect findings Histological clarification 2 – 90%
5 Suspecting carcinoma Histological clarification > 90%
6 Histolically confirmed carcinoma 100%

Other imaging diagnostic tools

In addition to the aforementioned methods, the following tests may be done:

1. Sonographie

  • Most important complimentary screening in addition to mammography
  • Benefit: no radiation exposure
  • Disadvantage: highly operator-dependent, not suited for screening
  • Criteria of malignancy: echo-poor, dorsal sound damping, unsharp ragged border contours, inhomogeneous, rarely with lateral shadow, cannot be compressed, surrounding structures disturbed
Breast cancer ultrasound images

Image: “Breast Cancer Ultrasound Images.” by Openi. License: CC BY 4.0

2. Galactography

  • Imaging of the milk-producing ducts using contrast agent injections, followed by x-rays with mammillary gland secretion.
  • Pathological findings: caliber fluctuations in the milk ducts, discontinue contrast agent.
Galactography suggestive of breast papillary lesions

Image: “Galactography suggestive of breast papillary lesions. A. Galactography with ductal tree display from the affected duct, showing a small retroareolar filling defect (in a circle). B. Galactography with filling defect (in a circle) in a magnified mammographic plate.” by Openi. License: CC BY 3.0

3. MRT

  • Conclusive findings are only possible with contrast agents.
  • Benefit: high soft-tissue contrast, very high sensitivity.
  • Disadvantage: low specificity, no detection of microcalcifications.
  • Indication: differential diagnosis: scar tissue/recurrence after surgery for mammary carcinoma, primary tumor screening in cases of axillary lymph node involvement, high-risk female patients, condition following reconstructive surgery.
A 50 year-old woman in the breast cancer group

Image: “A 50 year-old woman in the breast cancer group.” by Openi. License: CC BY 4.0

If metastases are suspected, pretherapeutic staging to include chest x-rays, liver sonography, as well as skeletal scintigraphy, should be pursued.

Biopsies in cases of mammary carcinoma

In order to further plan how to proceed and treat a patient if mammary carcinoma is suspected, it is necessary to histologically confirm the diagnosis. For this purpose, tissue samples are collected from the suspicious area via minimally invasive procedures and subsequently examined microscopically. The following procedures may be used:

1. Sonographically controlled punch biopsy.

Dermal punch

Image: “Dermal Punch” by William Rafti. License: CC BY 2.5

During an interventional punch biopsy which is, preferably, controlled sonographically, no less than three samples using a 14G core needle should be removed.

2. Stereotactically controlled vacuum biopsy (or MIBB: minimally invasive breast biopsy) under mammographic control, in cases of, among others, microcalcifications.

vacuum biopsy

Image: “Vorgang der Vakuumbiopsie” by Nico Vondung. License: CC BY-SA 3.0

3. Stereotactic excisional biopsy (or ABBI: advanced breast biopsy instrumentation), en bloc resection, especially in cases of microcalcifications.

Histology in cases of mammary carcinoma

After the tumor has been biopsied, it can be classified according to the TNM classification. The table in the first part of the article regarding mammary carcinoma will provide you with an overview.

Immunohistochemical staining of tumor cells is used in the diagnosis of tumors and may determine therapy. Hereby, the hormone receptors (estrogen, progesterone and steroid hormones), as well as the growth factor receptors (HER2/neu), play a role:

If more than 10% of the tumor cells stain positive for estrogen and/or progesterone receptors (ER/PR), the mammary carcinoma is hormone-receptor-positive. This means that it is suitable for endocrine therapy and has, in addition, a better prognosis.

Immunohistochemical analysis of estrogen receptor

Image: “Immunohistochemical analysis of estrogen receptor (ER) and progesterone receptor (PR) expression levels in breast cancer tissues.” by Openi. License: CC BY 3.0

In cases of an invasive mammary carcinoma, HER2/neu is overexpressed, which is referred to as HER2-positive. This status of over-expression indicates the direction of therapy: In cases of HER2/neu positive 3+, patients are treated with trastuzumab, an HER2 antibody.

Structure HER2

In cases of HER2/neu positive 2+, the FISH test has to be performed to check for HER2 gene amplification, which would indicate a more probable success of therapy.

In cases of HER2 1+ or HER2 0, a response to therapy is not expected as there is no over-expression.

Representative immunohistochemical staining images of HER-2

Image: “Representative immunohistochemical staining images of HER-2. The expression of HER-2 protein was detected by IHC. Representative HER-2 expression shown with 0 (A), 1+ (B), 2+ (C) and 3+ (D) subgroups. Scale bar: 100 μm” by Openi. License: CC BY 4.0

Differential Diagnosis

Symptoms similar to mammary carcinoma

The general goal is to differentiate between benign and malignant changes. Benign mammary tumors include, for instance, fibroadenomas or lipoms. Cystic changes, papillomas or mastopathy must be ruled out with regard to differential diagnoses; especially with symptoms of inflammatory mammary carcinoma, Mastitis non-puerpalis must be considered as differential diagnosis.

Therapy of Mammary Carcinoma

Neoadjuvant treatment of mammary carcinoma

In order to shrink large tumors (T4, T3), treatment may begin before surgery with chemotherapy or endocrine therapy.

Surgical treatment of mammary carcinoma

Breast cancer

Breast Cancer

Surgical treatment of mammary carcinoma includes the option to either radically remove the breast, or to opt for breast-conserving therapy with the same goal, namely to remove the tumor, as well as affected regional lymph nodes (in sano tumor resection, R0 status). The fact that this surgery is so radical does not, however, correlate with the chances of recovery, which is why the ground rule “as little as necessary“ should be applied.

Breast-conserving treatment of mammary carcinoma

Today’s standard method of surgical treatment is breast-conserving treatment (BCT), followed by radiation therapy of the remaining breast tissue. The prerequisite is that the tumor has not yet infiltrated the surrounding tissue and that there is a favorable ratio between the size of the tumor and the volume of the breast, which is the case in approximately 70% of female patients.

  • Lumpectomy: It usually involves an incision the shape of an oval above the tumor, removal of the tumor and the removal of healthy tissue the size of one centimeter as a secure border on all sides. In some cases, the removal of the nipple may be necessary as well. The removal of the axillary lymph nodes is done with a second incision.
  • Quadrantectomy: Removal of the quadrant of the breast where the tumor is located, as well as the axillary lymph nodes.
Breast conservation surgery

Image: “Breast Conservation Surgery” by Openi. License: CC BY 2.0

Mastectomy in cases of mammary carcinoma

In cases where the size or the extent, respectively, of the tumor, in cases of tumor multicentricity or if the patient is contraindicated for post-surgery radiation, BCT will not be an option. In those situations, or if the patient does not desire this type of procedure, a modified radical mastectomy (Ablatio mammae with axillary revision) is performed.

During this procedure, the breast, the axillary lymph nodes, as well as the pectoral fascia, are removed, while the pectoral musculature (as opposed to a Halsted radical mastectomy) is preserved. In cases of inflammatory mammary carcinomas, there is an indication for a mastectomy as well.


Image: “Mastectomie” by Acrocynus. License: CC BY-SA 3.0

The female patients must be educated on the option of breast reconstruction, which may take place simultaneously or after a latent period of at least six months. Suitable materials include heterologous implants or autologous tissue. Autologous tissue allows for the following flap technique reconstructions:

  • Thoraco-epigastric flap reconstruction
  • Latissimus dorsi flap reconstruction
  • (Transverse) Rectus abdominis (myocutaneous) flap reconstruction (TRAM)
Note: Both, mastectomy and BCT are to be regarded as equal with regard to survival rates, whereby the risk for a local recurrence is elevated for patients who have undergone BCT.



In order to determine a patient’s nodal status, it is necessary to perform a lymphonodectomy.

An axillary dissection is used for the removal of axillary lymph node fat tissue (level I and II) and is performed during BCT procedures, as well as during mastectomies. A minimum of ten lymph nodes must be removed and examined. Caused by the removal of the lymph nodes, there is an increased risk of lymphedema.

If the tumor is less than three centimeters in size, the axillary lymph nodes have not been affected and, if there are no contra indications (i.e. a multifocal, multicentric, metastasizing or inflammatory mammary carcinoma, Paget disease), the sentinel lymph node should be removed.

During this procedure, the lymph node that is attacked by the tumor cells first because of the lymph flow (sentinel/guardian lymph node), is marked via injection of peritumoral subdermal dye or radionuclide.

guardian lymph node blue

Image: “blau gefärbter Wächterlymphknoten (Axilla)” by Will Blake. License: CC BY-SA 3.0

If this lymph node is free of tumor (sentinel negative), the removal of the axillary lymph node is not necessary resulting in reduced shoulder-arm morbidity.

As a rule for SNL positive female patients (macrometastases), axillary dissection with removal of a minimum of ten lymph nodes from levels I and II is indicated.

Adjuvant therapy of mammary carcinoma

Adjuvant therapy takes place after the resection of the tumor with the goal to reduce the risk of a local recurrence and to eliminate potential tumor cells in the body. This can be systemically achieved via local radiation, chemotherapy, or via endocrine or monoclonal antibody therapy, respectively.


Adjuvant postoperative radiation (50 – 60 Gy) following BCT is an obligatory measure in order to reduce the risk of local recurrence. Following a mastectomy involving large tumors (pT3, pT4), in cases of skin infiltration or extensive lymphangiosis and if more than three axillary lymph nodes are affected, adjuvant radiation therapy is indicated.


Chemotherapy is indicated if there is an increased risk of recurrence and it should begin one to two weeks following surgery. The most frequent medications used are a combination of cytostatic drugs for which regular recommendations are established in guidelines and during the St. Gallen expert consensus conference. Anthracycline and taxane are currently considered to be the most effective chemotherapy drugs.

Monoclonal Antibodies

In cases of HER2/neu-positive cancers, it is imperative to administer the monoclonal antibody trastuzumab for one year in addition to chemotherapy (see above).

Endocrine Therapy

For ER-/PR-positive female patients (see above), endocrine therapy is indicated. The goal is estrogen deprivation in order to decrease the growth of carcinoma cells or even stop it, respectively. The standard medication being used is tamoxifen (20 mg/day, oral). Another option for premenopausal patients is the administration of GnRH analogs in order to suppress ovarian function. Aromatase inhibitors are indicated for postmenopausal patients.

There are the following therapy schemes:

  • Taking tamoxifen for five years.
  • Taking aromatase inhibitors for five years.
  • Taking tamoxifen for two to three years, followed by taking aromatase inhibitors for a total therapy duration of five years.
  • Taking aromatase inhibitors, followed by taking tamoxifen for a total therapy duration of five years.
  • Taking tamoxifen for five years, followed by taking aromatase inhibitors for five years.

Follow-up, Prognosis and Prevention of Mammary Carcinoma

Follow-up care in cases of mammary carcinoma

After locoregional primary therapy, follow-up is recommended. The gathering of the patient’s history, clinical and gynecological examinations, as well as instrument-based diagnosis (sonography, mammography), should be done.

Furthermore, there should be follow-up examinations every three months during the first three years, every six months during the fourth and fifth year, and annually after the sixth year. After a mammary carcinoma, the risk of contralateral breast cancer is two to five times higher which is why there should be an annual instrument-based check-up in that area as well.

Prognosis for mammary carcinoma

Basically, primary mammary carcinoma can be cured which is why therapy is curative. The chances of recovery depend on the tumor stage at the time the carcinoma is discovered. The earlier it is detected and treated, the better the prognosis.

Note: The most important prognosis factor with regard to remote metastases is if the axillary lymph nodes are affected!

In cases of remote metastases (in 5% of female patients when they are first diagnosed and in 30% of patients during the progression of the disease), therapy will take a palliative course as healing is no longer possible. The median survival time is approximately two years, the five-year survival rate is between 5 and 10% approximately.

Preventing mammary carcinoma

In order to prevent mammary carcinoma (primary prevention), the following options are available:

  • In cases of hereditary mammary carcinoma, a bilateral mastectomy with a risk reduction of 90% and/or a bilateral adnexectomy with a risk reduction of 50% should be considered.
  • In cases where the patient is at increased risk, drug therapy with tamoxifen, strictly according to indication, may be an option.

Early detection screenings serve as secondary prevention (see above).

Review Question

The answers are below the references.

1. During a breast self-exam, a 53-year-old female patient noticed a palpable resistance in the left mamma. She presents at her gynecologist’s office who, during the clinical examination, detects a palpable tumor, 1.2 cm in size. The tumor also shows up in sonography imaging. Which diagnostic step should be next?

  1. MRT examination of the mamma
  2. Mammography
  3. Galactography
  4. Stereotactically controlled vacuum biopsy
  5. CT-examination of the mamma

2. Which of the following mammography findings is the least likely indicator for a malignant tumor?

  1. Asymmetrical focal findings
  2. Inhomogeneous, band-like shadows
  3. Star-shaped thickening with spicules
  4. Homogeneous, dense findings, smoothly outlined
  5. Polymorphous, clustered microcalcifications

3. Which of the aforementioned therapy options are not suitable for treating a mammary carcinoma?

  1. Lumpectomy
  2. Modified radical mastectomy
  3. Systemic chemotherapy
  4. Antibody therapy
  5. Cerclage
